CM8600 ExT Series Dual System Refrigerant Charging Machine
CM8600(ExT)series Dual System refrigerant charging machine is specially designed to charge flammable refrigerant fluid R32,R600A...etc to refrigeration system assembly line.it combines all in one in order to perform evacuation, leak test and refrigerant charges to meet the customers demand for affordable high precision and high quality based on CM smart controltechnology, the charging machine uses the well known Siemens Programmer giving the user a colourful and convenient touch interface,you set the data,let the machine complete the job for you.
Application
Water dispenser, Air Conditioner, Beer machine, Freezers, Refrigerators,Vehicle,etc.

Feature
·Siemens smart PLC technology for fast and accurate operation process
·Large colorful touch screen make the operation easy and simple
·High precision mass flowmeter technology ensures charging accuracy
·Powerful pneumatic booster pump for high speed charging rate
·The continuous charging quantity up to 99999g
·Automatic reminder function when the liquid supply tank is lack of refrigerant
·Combine vacuum, leakage inspection, refrigerant charging to all in one system
·Equipped with leakage alarm device
·High charging accuracy
Please contact us by email ---->
Main Features And Advantages
Smart linear algorithm ensure high charging accuracy
Require no daily charging accuracy calibration
-10℃~50℃ testing to ensure charging stability
Gas leakage detection monitoring
Siemens PLC
CE/ATEX certificate

Specification:

Model

CM8600(ExTSeries)

Serial No.

ExT40

ExT60

Charging speed

≥40 g/s

(2.4 kg/min)

≥60-80 g/s

(3.6-4.8 kg/min)

Single charge amount

10-999999g

10-999999g

Charging accuracy

Less than 500 g, ≤2 g

500 g-2000 g,≤±0.5%

2000 g,≤±0.3%

Measurement methods

RRT American Ruby Flow Meter

Resolution ratio

0.1g

Certificate

CE/ATEX

Vacuum rate

4L/S

8L/S

Vacuum degree of machine

3-5pa

Charging gun port

Hansen 1/4 or 3/8 quick connectors

Length of charging gun

Standard with 3 meters, other specifications 3-10 meters optional

Communication interface

RS485/RS232/Ethernet

Channels quantity

100

Compressed air pressure

0.5-0.7Mpa

PLC

Siemens

Power supply

380V 50Hz 3Phase or 220V 50Hz 1Phase

Dimension

900*800*1340 mm

Approved refrigerants

R600a、R290、R32、R1234ze、R1234YF、R134A etc.

Application

Air ConditionWater CoolerBeer MachineFreezers, refrigerators, chillers, heat pumps,etc.
