CM580S Refrigerant Recovery Machine

CM580 S series refrigerant recovery machine is specially designed for waste air condition and refrigerator disassembly line with high efficiency recovery rate,it utilizes three -stage oil less compressor with explosion proof motor and electrical control box can be used to recovery various flammable and common refrigerants,the machine can also remove the oil and impurity from your dirty refrigerant during recovery process.

Application

Waste Recycling Factory

Feature

·Powerful oil less compressor compatible with CFC/HCFC/HFC refrigerants

·Ultra fast recovery rate for vapor refrigerants

·Simple operation in vapor and liquid push/pull recovery exchange

·Perfect protection cut-out function – safe credibility

·Two stage cooling for high efficiency heat exchange rate

·High vacuum degree -0.09Mpa allow recovery more refrigerant for avoid refrigerant lose

·Equipped with explosion proof motor and control box for flammable refrigerant

·Once recovery finished,machine stop automatically

·High efficiency oil separator and filter drier for removing oil and moisture

Specification

Model	CM580S
Horsepower	25HP
Compressor Displacement	57m³/h
Compressor Type	Three-stage compression oil-free reciprocating
Vapor Recovery	≤350Kg/h
Liquid Push&Pull Recovery Rate	≤15000Kg/h
Cooling	Air Cooled&Water Cooled
Applicable Refrigerant	R290/R600A/R32/R410A/R134a/R22/R407C etc.
Gas Leakage Monitoring	Yes
HP Shut-off	Yes
LP Shut-off	Yes
Oil Separator	Yes
Power Source	380~460V 50Hz 3Phase
Certification	ATEX

Please contact us by email ---->

Main Features and Advantages:

Large displacement oil less compressor

Low vaccum degree -0.095Mpa

Capable of handling over 20 AC per cycle

Pressure detection device

Applicable to flammable refrigerants

ATEX Certification
